Comparison Model
Model: Rubi Bore 1.10 IC Smart
Boring Range3.268 - 4.725 in (83 - 120 mm)
Boring Depth14.625 in (371 mm)
Cylinder Block Length30.325" x 13.790" x 16.300" (770 mm x 350 mm x 414 mm)
Spindle Speed60 – 1200 RPM
Spindle Feed0.001 - 0.012 in (0.001 - 0.300 mm)
Electrical Supply220 V / 50-60 HZ / 3 PH
Model: Rubi Bore 1.9 IC Smart
Boring Range2.750 - 4.488 in (70 - 114 mm)
Boring Depth12.625 in (320 mm)
Cylinder Block Length30.325" x 13.790" x 16.300" (770mm x 350 mm x 414mm)
Spindle Speed60 – 1200 RPM
Spindle Feed0.001 - 0.012 in (0.001 - 0.300 mm)
Electrical Supply220 V / 50-60 HZ / 3 PH
Model: Rubi Bore 1.9 F Smart
Boring Range2.750 - 4.750 in (70 - 122 mm)
Boring Depth12.625 in (320 mm)
Cylinder Block Length30.325" x 13.790" x 16.300" (770 mm x 350 mm x 414 mm)
Spindle Speed60 – 1200 RPM
Spindle Feed0.001 - 0.012 in (0.001 - 0.300 mm)
Electrical Supply220 V / 50-60 HZ / 3 PH
Model: Rubi Bore 1.5 Smart
Boring Range2.205 - 4.135 in (56 - 105 mm)
Boring Depth10 in (254 mm)
Cylinder Block Length20" x 15.750" x 13" (508 mm x 400 mm x 300 mm)
Spindle Speed60 – 1000 RPM
Spindle Feed0.001 - 0.008 in (0.025 – 0.200 mm)
Electrical Supply230 V / 50–60 Hz / 1 Phase
Model: Rubi Bore 1.2 Smart
Boring Range1.750 – 3.350 in (45 - 85 mm)
Boring Depth9 in (228 mm)
Cylinder Block LengthSingle cylinder block
Spindle Speed200 – 800 RPM
Spindle Feed0.001 - 0.008 in (0.025 – 0.200 mm)
Electrical Supply230 V / 50–60 Hz / 1 Phase
