The SG5.1 model from Robins stands out as the market’s most dependable and cost-effective cylinder head seat and guide machine. Robins integrates precision carbide centering pilots with a lightweight air float work head, ensuring flawless centering with the valve guide consistently. This machine is the preferred option for workshops specializing in the repair of performance products, both domestic and imported cylinder heads, as well as motorcycle-style cylinder heads. Robins offers the flexibility to customize the machine’s tools according to the specific specifications of the machine shop.
+| Machine weight | 925 lbs (420 kg) |
| Max cylinder head size | 23″ x 10″ x 5″ (584 mm x 254 mm x 127 mm) |
| Work head travel | 18.200″ (462 mm) |
| Spindle stroke | 5.750″ (146 mm) |
| Spindle stroke | 0.75 HP |
| Variable speed spindle | 70 - 580 rpm (60 hz) |
| Spindle tilt | ± 10 Degrees |
| Compare Model Specs |
Current Model
|
No related products found
|
|---|---|---|
| FEATURES |
Combo 1.10
|
No related products found
|
| Machine weight | 925 lbs (420 kg) | |
| Max cylinder head size | 23″ x 10″ x 5″ (584 mm x 254 mm x 127 mm) | |
| Work head travel | 18.200″ (462 mm) | |
| Spindle stroke | 5.750″ (146 mm) | |
| Variable speed spindle | 70 - 580 rpm (60 hz) | |
| Spindle tilt | ± 10 Degrees | |
